req, quick answer about CC please
#1
Scooby Regular
Thread Starter
req, quick answer about CC please
I recently aquired an oil CC, but unfortunatley it came with no instructions, so after doing a search around the www ,I found these pics.
can anyone tell me if this is the correct way to fit it before I make a start ?
Ive heard that I'll need "T" peices, but from the photos it looks like non are used, can anyone confirm this ?
thanks
Phil
can anyone tell me if this is the correct way to fit it before I make a start ?
Ive heard that I'll need "T" peices, but from the photos it looks like non are used, can anyone confirm this ?
thanks
Phil
#2
theres a breather on the right hand side of the engine aswell can't see this in the pic
my instal
http://bbs.scoobynet.co.uk/showthread.php?t=296443
my instal
http://bbs.scoobynet.co.uk/showthread.php?t=296443
Last edited by fuz; 18 July 2004 at 10:53 AM.
#3
The 2 cam cover breathers join together under the manifold and go to the inlet pipe, the crankcase breather goes to the inlet pipe. T these together and fit to one connector on the can. Other outlet on can goes to atmosphere ( by a/r bar say !! ) or to one of holes in inlet hose, blank off other.
See comments on the group buy thread.
See comments on the group buy thread.
#5
Scooby Regular
iTrader: (5)
Join Date: Feb 2003
Location: Worcester
Posts: 2,625
Likes: 0
Received 0 Likes
on
0 Posts
guys Im in the same boat as madgrip has any one got any dummy instructions so I can set it up my self or at least check it over if I get the local subaru garage to fit it
Thanks
Rich
Thanks
Rich
#6
Scooby Regular
iTrader: (55)
Fitted mine this weekend just gone and I ran a pipe from each crankcase breather and another pipe from the breather near the turbo (98 car) Blanked all 3 to the inlet manifold then T'd all 3 together and attached to catch can. Pipe then from can to atmo.
Is this correct ?
Is this correct ?
