99greenwagon

iTrader: (39)

hi,is it possible to have the oe airbox still in place when having a fmic fitted or do you have to run an induction kit?(98 sti type r)
thanks.

snake1906

iTrader: (4)

induction kit m8

99greenwagon

iTrader: (39)

thanks,what is best to use?

snake1906

iTrader: (4)

id say go with k&n or if you can find the extra pennys get 1 from rcm,they work alot better than most others and there more maf friendly they are the only 2 i would use

SCOOBYOLS46

I would recommened either Hks green mushroom filter or roger clark motorsports induction kit mate

99greenwagon

iTrader: (39)

ok,i have got a rcm kit lined up,im planning on fitting a hybrid fmic and the rcm kit to my 98 sti type r. is this straight forward with the rcm kit,i have oe pipework for intake,ive read a guide on how to fit the front mount,dosent seem too bad,will i be able to reuse my oe black plastic dump valve??
is there anything i should be aware of?thanks.

mickywrx

iTrader: (29)

Shouldn't be too hard to re-use the OEM re-circ. You may need to get an adaptor, which I think Harvey sells.

I'm using the OEM one on mine.

99greenwagon

iTrader: (39)

thanks,the fmic pipe has a outlet bit on it towards where the dump valve goes so im assuming that the pipe for dump valve will fit directly to it.

99greenwagon

iTrader: (39)

also,being the type r mine has an ic water spray tank near drivers side headlight,so would i just remove this for good along with ic water spray pipes and undertray etc etc?

mickywrx

iTrader: (29)

Have you got a pic of your OEM dump valve?

Yeah, you could remove all the associated water spray kit. I would keep it in case you put the car back to standard though.

99greenwagon

iTrader: (39)

havent got any pics atm,the intercooler has a right angled tube coming off of it with a hose attached,the recirc valve is pushed into this hose at the bottom,its a black plastic one that im assuming comes as oe on all v4 type r's.

joz8968

iTrader: (13)

Yeah the OEM one on a v.4 (and v.3) is black plastic, with the inlet and outlet at right angles to each other. You can reuse it.

You need a suitable bit of silicone to recirc it back to the recirc port on the turbo intake hose (if it's not already fitted). Also, don't forget the small 3-4mm vac hose that goes form the top of the DV to the inlet manifold...

99greenwagon

iTrader: (39)

yeah,sorted mate,thanks,have you ever fitted a fmic before joz?
also,is there anything i should know about the existing pipework etc regarding the oe airbox when i come to fit the rcm induction kit?

joz8968

iTrader: (13)

Fit the FMIC first. Then worry about the intake after. You normally have to 'plan' the intake side of things once you know where/how the driver side FM's hard pipe sits...

99greenwagon

iTrader: (39)

but im hopeing i can just reuse the oe intake and fix the rcm induction kit to it which will hopefully run above the i/c pipe?

joz8968

iTrader: (13)

Yeah, most FMIC's allow the cone (and/or MAF/intake pipe) to run OVER the pipe. The Hybrid GT Spec and Spec2 does, for example.

But my Hyperflow one only allows the filter underneath - so it's quite a small filter (but good enough for big(ish) power, so not an issue).

99greenwagon

iTrader: (39)

ok so once i have the fmic and pipes and the rcm induction kit i shouldnt need anything else?
i have spare jubbly clips and vacuum pipe etc,just dont want to miss anything major and find out halfway through the job.

mickywrx

iTrader: (29)

You'll need a suitable reducer to connect the dump valve to the FMIC pipe.



That's how mine is plumbed in, yours will be slightly different though.

99greenwagon

iTrader: (39)

thanks for that,ill wait till the fmic and pipes arrive as there may be a reducer left on the existing fmic pipe.
hopefully anyway,if not.....is that likely to be the only thing i would need to complete the job including fitting the rcm kit?

joz8968

iTrader: (13)

Micky, I think his DV is already sorted on the FMIC's hard pipe... see post # 11

99greenwagon

iTrader: (39)

sorry joz , i was actually refering to my tmic,but as above im hoping the fmic pipe comes with a reducer or similar,as it certainly has an outlet for the recirc valve at the top of the pipe(just before it goes to the throttle body) so im hopeing it will fit.ill have to wait and see.

99greenwagon

iTrader: (39)

i think the hard pipe is almost identical as the one pictured above,the outlet also looks like its in the same place.

99greenwagon

iTrader: (39)

if you look closely at the top you can see the outlet,the intercooler comes with all the pipes,silicone joiners etc so fingers crossed it will have the reducer with it.

joz8968

iTrader: (13)

All you need to do is measure the outer diameters of the DV's inlet port and the FMIC's DV port. Then get a suitable reducer silicone with the correct inner diameters. There're loads on eBay in all different shapes/sizes...

99greenwagon

iTrader: (39)

ill have a good look at it when it all arrives and ill sort it out,do you know of any guides for fitting front mount intercooler on classic? ive only found one which is ok but very basic.
i need one thats idiot proof!

joz8968

iTrader: (13)

I think I know the one you're on about - on an early classic right?

That guide seems comprehensive enough if you ask me. But of course it will be different depending on the kit you've got i.e. pattern of pipes, etc...

99greenwagon

iTrader: (39)

its a 2nd hand hybrid fmic kit,the tmic i have is not the late one where the recirc valve bolts direct to i/c.
its the v4 and has a right angled outlet port on it which a pipe connects to(the recirc valve being in the other end of the pipe)

will my motor be ok to drive approx 140 miles with a fmic and induction kit fitted so i can get it mapped?

joz8968

iTrader: (13)

Yes, just don't use any boost. Drive normally with minimal throttle to get up to speed.

I'd bend harvey's ear when fitting it if you have probs. He's very helpful in that regard - plus he's fitted hundreds of the damn things lol...

99greenwagon

iTrader: (39)

thanks joz

joz8968

iTrader: (13)

Oh, and whilst you're doing it, then it would be a perfect opp. to replace the spark plugs...
