blackpoolrock

Ive been to the rollers today to get a power run after the latest mod of a new turbo - only got 435 and 360lbft.

my mods are

Custom Turbo from latereal
gt2 spec headers
Harvey up pipe
850cc injectors
harvey FMIC
3" down pipe
3" exhaust

i was only boosting at 1.5 bar peak and after talking to Mark at lateral it seams im good for alot more boost from the turbo, so my question to the boys over 450 bhp -

what are you boosting at ?

cuprajake

iTrader: (11)

You may be able to produce more power but can the engine take it? Is it not better to be tuned safe and reliable. Rather than maxing everything and potentially destroying it.

I'd never 100% go as gospel with a rr anyway. If I'd drives right and is doing what it should I wouldn't chase figures personally

blackpoolrock

yeh its properly quick now jake, and to be fair your right , ive always asked to have it maped on the safe side. id just be interested to know what others are boosting at, if the 450bhp+ guys are at similar boost levels id be a little gutted but if they are 2 bar plus id be happy !

Jacko4130

iTrader: (3)

I run 429/380 at 1.8 bar peak and dropping to 1.7 to redline

I know its not over 450 but gives your some idea.

blackpoolrock

thanks jacko

i got more bhp but you got more lbsft

your on moor boost

KK3960

iTrader: (21)

Mines a similar spec on standard internals MD321t and a large Hyperflow top mount and ran 431 / 361 at Prosport without the Harvey up pipe and on the GT spec up pipe. I was peak boosting around 1.5 Bar. I've just had Lateral billet my 321t and re-fitted it with a Harvey up pipe this weekend, supplied by Alyn at ASP, Andrew Carr is mapping it next week and I'm aiming for 440-450HP and 380Lbs torque, anything more will be a bonus, I'll keep you posted on Lads. I've an AVCR fitted to keep an eye on boost and trim it accordingly, I wouldn't want to run it at that power on standard internals without some form of monitoring or controlling boost.

blackpoolrock

pretty much the same then - my turbo is a M321t with a billet V wheel and t exhaust wheel. Mark at lateral has said good for 470 - 480 on pump fuel but need to increase boost !

are you on a 2.5 ? im on a 2L

stevebt

iTrader: (8)

Just short of 2.2bar on a billet gt35r

stevep360

iTrader: (20)

1.9bar on a billet GT35r Billet, more if Martyn wanted to turn up the wick.

KK3960

iTrader: (21)

Yep mines a 2.0 I have just bought a built 2.3 so will be dropping that in next year with a GT30 billet or GT35. I'd like to see 450hp on the standard internals with the billet T at 1.7 bar max but see where we go.

blackpoolrock

what power ?

The Pink Ninja

iTrader: (23)

Whats that then Ste....About 650bhp?

I`m on Standard spec, lol....Turbo,ECU,Topmount,Airbox @ 1.65 bar around 360bhp/380lbft on JDM 2.0 spec-c, Peak torque at 3300rpm

speedflash

1.65 md321t+ gt spec and the Harvey up pipe you have.20% meth

492 bhp 380 ftlb standard sti 8 lump sweet as a nut.

wrx9181

iTrader: (2)

Nice gaz
But spec c s don't count lol

blackpoolrock

WOW !!

The Pink Ninja

iTrader: (23)

, Its all about the torque,

Keep thinking about a TS SC42 but have resisted for the last 2 years

stevebt

iTrader: (8)

I don't know as mapping was done on the road and we maxed my id1000cc injectors out at 4bar fuel pressure after a couple of pulls, Andyf's bum dyno says its 660bhp? I need bigger injectors so more power and 2.3bar

banny sti

iTrader: (68)

2.1bar on a billet GT35R

blackpoolrock

power ?

banny sti

iTrader: (68)

666

Tidgy

what did the mapper say? he would know whast going on, iof the turbo is giving all it has to give, did he map is safe etc etc

whast the engine?

Tidgy

you is the devil!!! hahahaha

jura11

iTrader: (7)

Hi there

We are run before on MDX321T 1.7bar and we are made 452bhp on V-power and 490bhp on V-power and 20% methanol

Sometimes more boost(on some turbo)doesn't mean you will be making more power,in some cases you will make less power,because more boost only create more heat not power

Jura

Shaun

There is more to tuning than boost.

Some turbos, engine and anxillaries will suit certain mapping strategies. Each car is different as well.... none are the same. The mapping can make a big difference as well.... way too many variables imo.

Peak boost will lean towards your torque figure, whilst boost at peak power will support peak BHP figures. These can be totally different boost levels though. You'd need to know what the car makes at peak boost and also peak power.

I have a LM450 Billet (similar turbo to yours) on my standard 2ltr and make 442bhp/440ftlb on VPower @ just under 1.8bar peak boost and 1.7bar peak power.

On Methanol I make 480bhp/465ftlb @ 1.75bar peak boost and 1.6bar peak power.

My torque levels are quite substantial though and always have been on my set-up.

However.... the boost levels don't mean a fat lot when you don't know how much ignition people run either.

So..... don't concentrate on boost alone - discuss this with your mapper for his opinion. AFR's can make a difference on power outputs as well.

I could have had my map pushed further for the sake of a dyno plot, but I'm not interested in that....... it's a standard engine and needs the best chance of staying in one piece, being safe whilst being very quick. Not always a given and you'll also be advised that a dyno graph will only give an indication of how quick a car could be. It's not the be all and end all.

Power


Boost

blackpoolrock

Wow thanks for the info guys ! Ill be leaving it to my mapper !!

KK3960

iTrader: (21)

Who's mapping it for you?
