super_ted

iTrader: (30)

Anyone managed to split a newage sti intercooler by running 1.5bar through it? Mine seems to be leaking between the folded joint at the top.

I thought these could handle up to 400bhp?

Badger sti

My sons has split on his WR1 but being replaced by Crossroads under warranty.

super_ted

iTrader: (30)

Where has it split just out of interest?

Badger sti

at the front above the manifold inlet pipe. there is a black shadow where the air has been escaping

super_ted

iTrader: (30)

Right, after a weekend at the santa pod i noticed performance was down. I took a good look around the engine bay as i could what i suspected to be a small boost leak whilst on full boost. I removed the top mount to have a closer look and noticed oil all over the bottom of it but could not trace it to any particular section.
So after having a little think i came up with this idea to pressure test it, all found in my garage so it cost me nothing.

Materials:
One empty food can
15mm speed fit pressure tester
15mm brass tank connector
silicone
section of copper pipe
Plastic lid
Bike pump

Came up with this



The turbo side is blocked with a clear lid which is clamped, you just cant see it very well as it's clear. Anyway i began to pump & soon found this with the aid of some soapy water.......



New intercooler time

jura11

iTrader: (7)

Not looking good there,great testing method.

Do you thinking get again TMIC or you will go with FMIC?



Jura

super_ted

iTrader: (30)

Depends what comes up first i guess although only having had it re mapped for tmic set up, i dont really want to have another re map so soon if i go fmic set up.

Badger sti

What pressure was it leaking at?

super_ted

iTrader: (30)

Straight away, no pressure would even build up, so leaking a lot.

mickywrx

iTrader: (29)

That's not good.

Mr Windscreen

iTrader: (6)

Did you get a loud hissing sound on full boost? I,ve got a simular problem with my bug. Haven,t checked tmic yet.

super_ted

iTrader: (30)

Yes it was a loud hissing / squealing noise under full boost which as time went on, got worse. A bit annoying as i bought it not that long ago £100 odd down the drain lol.

Badger sti

Have you thought about trying to get it repaired. Motorads in Redditch may be able to help but I don't know the cost. New STI intercooler nearly 700 quid.

Rob Day

iTrader: (78)

Give it to a Radiator specialist, there's one near me. They'll fix that for you
