stupid question time
hi folks,
looking at getting rid of the VTA DV for this http://cgi.ebay.co.uk/ws/eBayISAPI.d...#ht_500wt_1156
question is, where on earth does the standard thick pipe connect to?
classic facelift wagon 2000 turbo
magnex exhaust
bailey DV
MY99 V plate
thanks
looking at getting rid of the VTA DV for this http://cgi.ebay.co.uk/ws/eBayISAPI.d...#ht_500wt_1156
question is, where on earth does the standard thick pipe connect to?
classic facelift wagon 2000 turbo
magnex exhaust
bailey DV
MY99 V plate
thanks
#2
Scooby Regular
iTrader: (14)
Join Date: Sep 2010
Location: North Yorkshire
Posts: 647
Likes: 0
Received 0 Likes
on
0 Posts
One end to the recirc valve, the other to the pipe at the back right hand side of the intake manifold. It should have been bunged/capped like this to run the VTA in the first place:
Remove the bung and refit the recirc pipe
In the pics I've removed the DV but you can see one of the bolt holes for the flange mounting at the front right hand side of the intercooler. This will give you a good reference point to the pipe you're looking for...
James
Remove the bung and refit the recirc pipe
In the pics I've removed the DV but you can see one of the bolt holes for the flange mounting at the front right hand side of the intercooler. This will give you a good reference point to the pipe you're looking for...
James
Last edited by P1#1015; 01 February 2011 at 03:16 PM.
