Hi guys got one more pic of the engine, only got one more pipe to connect up, its the top black one in the picture...........please someone has got to know where this goes.....



On mine it goes back into the inlet pipe after the maf sensor.



It goes to the turbo nipple mate.




BMPoser, ????





Hmmm its quite a short pipe, the only thing i can see it could possibly fit onto is to a little plastic stump that is coming out of the resistor box, could this possibly be what it attaches to?



Is it not coming off the top of the BCS?

The stump on the res box is for the bottom pipe on the BCS.



i think its where it goes, to the resistor box



Ahhh, well the bcs aint mounted to anything so that pipe thats not connected can either be the top or the bottom of the bcs. Im not 100% sure but the other end is def not connected to the rez box sump.... Ill have a check tomoz and see what the other pipe is connected to....



@billy: yea im pretty sure your right geez!



That top pipe is meant to be the feed pipe from the turbo outlet, the next one down (middle pipe) should be from the wastegate actuator and the bottom one should be to the intake/res box and should also have a restrictor pill in that pipe as std.

Cheers Iain



Sorry, it is as pic above, i got the pipes mixed up as i followed them down as there all wraped together.



Think again then!

What the **** is a resistor box

The BCS in your pic is the correct way up. Just plumb it as per the pic i posted.

It's not fukking rocket science.

@billy:Yeah, i'm pretty sure your talking shiot.
