Air Charge temp test
#1
Scooby Regular
Thread Starter
Air Charge temp test
I have just fitted a temp probe after my newage WRX Intercooler, in the pipe that connects it to the inlet manifold.
I want to see if I need better intetcooling.
2.0 with big 16g running 353bhp and peak of 1.7 bar, anyone want to hazard a guess what temps I'll see? Not driven the car since fitting the gauge
I want to see if I need better intetcooling.
2.0 with big 16g running 353bhp and peak of 1.7 bar, anyone want to hazard a guess what temps I'll see? Not driven the car since fitting the gauge
#3
Scooby Regular
iTrader: (2)
I have just fitted a temp probe after my newage WRX Intercooler, in the pipe that connects it to the inlet manifold.
I want to see if I need better intetcooling.
2.0 with big 16g running 353bhp and peak of 1.7 bar, anyone want to hazard a guess what temps I'll see? Not driven the car since fitting the gauge
I want to see if I need better intetcooling.
2.0 with big 16g running 353bhp and peak of 1.7 bar, anyone want to hazard a guess what temps I'll see? Not driven the car since fitting the gauge
#5
Scooby Regular
Thread Starter
#7
Scooby Regular
Thread Starter
Better intetcooling will always yield more timing/power so it's always a benefit. But no, you don't need it at that power, nor do you need the pinks 👍
Trending Topics
#10
Scooby Regular
Thread Starter
For sure, more boost is more power though, if you can keep it cool. I'll not be going to STi top mount or front mount route, I would be using a charge cooler if I find my ACT's are high.
#11
Scooby Regular
Thread Starter
14 mile drive to work today, ambient temp started off about 3 degrees, rising to about 6 degrees by the time I got to work. The only pulls i could do (running out of road/getting too much speed up etc) I managed to get the temps up to 14-18 degrees, so about 10 degrees above ambient. This is holding it at 1.7 bar for 10 seconds or so, bit of left foor braking too just to add load to the system.
More testing required for sure, but the OEM intercooler doesn't look bad?
More testing required for sure, but the OEM intercooler doesn't look bad?
#12
Scooby Regular
iTrader: (2)
It's not day to day driving you need worry about. Mine was fine at 300bhp on an STi6 intercooler...........until I did a bit of "spirited" driving against a GT4 on a vfrench motorway, arrived at a toll booth, queued and drove away, to find that heatsoak had killed the engine.
I now have one of Harvey's FMIC's, my temperature probe shows about 6 deg above ambient, never more.
I now have one of Harvey's FMIC's, my temperature probe shows about 6 deg above ambient, never more.
#13
Scooby Regular
iTrader: (11)
Join Date: Oct 2010
Location: Herefordshire
Posts: 2,760
Likes: 0
Received 0 Likes
on
0 Posts
I have a new age intercooler fitted to my V3 STi and have a temp gauge fitted in the exit of the intercooler in the flow of air to the throttle body so a similar place to yours.
I find that in normal driving mostly off boost type stuff I run at about 6 degrees C above ambient. If I give it the beans it'll obviously run higher but with the bigger intercooler the temp comes down quite rapidly. A bigger intercooler is well worth it to get temps down quicker.
I find that in normal driving mostly off boost type stuff I run at about 6 degrees C above ambient. If I give it the beans it'll obviously run higher but with the bigger intercooler the temp comes down quite rapidly. A bigger intercooler is well worth it to get temps down quicker.
#14
Scooby Regular
Thread Starter
It's not day to day driving you need worry about. Mine was fine at 300bhp on an STi6 intercooler...........until I did a bit of "spirited" driving against a GT4 on a vfrench motorway, arrived at a toll booth, queued and drove away, to find that heatsoak had killed the engine.
I now have one of Harvey's FMIC's, my temperature probe shows about 6 deg above ambient, never more.
I now have one of Harvey's FMIC's, my temperature probe shows about 6 deg above ambient, never more.
Heatsoak is an issue (on the drag-strip que perhaps), but cant this be fixed with fans? As an intercooler it seems to work well
#15
Scooby Regular
iTrader: (3)
perrin did some testing which could be of use here:
http://blog.perrinperformance.com/th...ercooler-test/
They saw around 60-65 degrees on their standard top mount test.
Out of curiosity, where did you get your sensor kit - any pics of it installed?
http://blog.perrinperformance.com/th...ercooler-test/
They saw around 60-65 degrees on their standard top mount test.
Out of curiosity, where did you get your sensor kit - any pics of it installed?
#16
Scooby Regular
Thread Starter
perrin did some testing which could be of use here:
http://blog.perrinperformance.com/th...ercooler-test/
They saw around 60-65 degrees on their standard top mount test.
Out of curiosity, where did you get your sensor kit - any pics of it installed?
http://blog.perrinperformance.com/th...ercooler-test/
They saw around 60-65 degrees on their standard top mount test.
Out of curiosity, where did you get your sensor kit - any pics of it installed?
Looks gansta, Its just poked tight in a hole through a temporary silicon connector after the intercooler.
#17
Scooby Regular
iTrader: (11)
Join Date: Oct 2010
Location: Herefordshire
Posts: 2,760
Likes: 0
Received 0 Likes
on
0 Posts
Even when I thrash my car around in really hot temps I don't see a lot more than mid 40's at most. That's country lane type thrashing so up and down the box. On motorways/Dual carriageways it doesn't get anywhere near as hot as that.
If it's parked up after a bit of 'spirited driving' or stuck in very slow/stationary traffic I've see temps up to 60-65 but once the traffic moves the temps fly down.
Front mount will always be better and more consistent with temps as it's not sat on top of the engine.
If it's parked up after a bit of 'spirited driving' or stuck in very slow/stationary traffic I've see temps up to 60-65 but once the traffic moves the temps fly down.
Front mount will always be better and more consistent with temps as it's not sat on top of the engine.
#18
Scooby Regular
Thread Starter
Even when I thrash my car around in really hot temps I don't see a lot more than mid 40's at most. That's country lane type thrashing so up and down the box. On motorways/Dual carriageways it doesn't get anywhere near as hot as that.
If it's parked up after a bit of 'spirited driving' or stuck in very slow/stationary traffic I've see temps up to 60-65 but once the traffic moves the temps fly down.
Front mount will always be better and more consistent with temps as it's not sat on top of the engine.
If it's parked up after a bit of 'spirited driving' or stuck in very slow/stationary traffic I've see temps up to 60-65 but once the traffic moves the temps fly down.
Front mount will always be better and more consistent with temps as it's not sat on top of the engine.
I am considering a charge cooler to keep the boost pipe lengths short, increase flow and keep the temps cooler for longer.
#19
Scooby Regular
iTrader: (11)
Join Date: Oct 2010
Location: Herefordshire
Posts: 2,760
Likes: 0
Received 0 Likes
on
0 Posts
The temps I quoted are pretty extreme examples but once the car's moving, even fairly slowly the temps come down steadily. I also have intercooler spray which helps a lot after heat soak.
#20
Scooby Regular
Thread Starter
#22
Scooby Regular
iTrader: (2)
I will go have a look, my temp gauge is just an LCD battery operated thermometer, bought it off ebay a hundred years ago, quite accurate as it shows my body temp bang on the money.
Looks gansta, Its just poked tight in a hole through a temporary silicon connector after the intercooler.
Looks gansta, Its just poked tight in a hole through a temporary silicon connector after the intercooler.
I monitor pre- intercooler temps and they can fluctuate between 70c up to 140c and back down in a split second depending on the pressure of my right foot. For measuring heat soak this wouldn't matter of course.
The figures you've posted seem good though and are confirmed by the power being achieved on a wrx topmount
#23
Scooby Regular
Thread Starter
to be accurate the device needs to read at least twice a second as it could well miss the temperature spikes being produced by the turbo.
I monitor pre- intercooler temps and they can fluctuate between 70c up to 140c and back down in a split second depending on the pressure of my right foot. For measuring heat soak this wouldn't matter of course.
The figures you've posted seem good though and are confirmed by the power being achieved on a wrx topmount
I monitor pre- intercooler temps and they can fluctuate between 70c up to 140c and back down in a split second depending on the pressure of my right foot. For measuring heat soak this wouldn't matter of course.
The figures you've posted seem good though and are confirmed by the power being achieved on a wrx topmount
Did a pull in way home, 1-2-3, top end of 3rd was showing 42 degrees! 11 degree ambient. Came down pretty quick
#24
Scooby Regular
iTrader: (2)
Join Date: Jul 2010
Location: Over the Pond, North side!
Posts: 165
Likes: 0
Received 3 Likes
on
3 Posts
Always interesting to read these type of threads.
I've been looking into this and the good old debate of 'TMIC versus FMIC' but I don't want to take this off subject but there was some good points in this thread https://www.scoobynet.com/954531-bhp...nd-fmic-4.html
It's interesting when you look at flow through the intercooler rather than just size!
I've been looking into this and the good old debate of 'TMIC versus FMIC' but I don't want to take this off subject but there was some good points in this thread https://www.scoobynet.com/954531-bhp...nd-fmic-4.html
It's interesting when you look at flow through the intercooler rather than just size!
#26
Scooby Regular
Thread Starter
Always interesting to read these type of threads.
I've been looking into this and the good old debate of 'TMIC versus FMIC' but I don't want to take this off subject but there was some good points in this thread https://www.scoobynet.com/954531-bhp...nd-fmic-4.html
It's interesting when you look at flow through the intercooler rather than just size!
I've been looking into this and the good old debate of 'TMIC versus FMIC' but I don't want to take this off subject but there was some good points in this thread https://www.scoobynet.com/954531-bhp...nd-fmic-4.html
It's interesting when you look at flow through the intercooler rather than just size!
I just wonder how many people have installed a fmic when they didn't really need to.
I was stuck on a below expectation 380hp and the advice from two top mappers was to go front mount.
What actually was happening was the oem dv was bleeding boost, causing the turbo to overwork, creating excessive heat, 180c+ pre intercooler. The short of it is, the dv was replaced,temps now 137c pre-intercooler at 1.6bar, the car went on to produce 421hp on straight Vpower, (at 380hp it was on Vpower/10%meth with no further progress possible). On 20%meth it produced 441hp/480lbsft, all this on a 400hp turbo, the MD321H. The tmic is an AVO which is a good bar and plate type and slightly smaller than the V8 STI TMIC.
Ok, I run a water/meth injection system which helps bring the ACT's down to 5/6 degrees of ambient and EGT'S of 600C at full boost. Previously the W/M system was only helping to mask the problem of the overworked turbo by keeping ACT's in some sort of check.
My next step is to fit a BILLET T which I'm hoping will give me another 30hp and a stronger top end which the H does lack on my set-up.
My point is more work should be done on whats coming out of the compressor wheel end of the turbo because in my experience it can vary enormously and any intercooler be it top or front would be challenged by temps of 180c+ and a lot better off with something around 130c.
Trev
#27
Scooby Regular
Just sold a spare STi top mount I had. It came with the IC to TB hose though so I've kept that as I was going to rig something up for mine to monitor the temp also.
Don't forget you're doing this in November also, in July your 42 degrees would be a **** load more!
Don't forget you're doing this in November also, in July your 42 degrees would be a **** load more!
#28
Scooby Regular
Thread Starter
yeah the temps are 32 degrees above ambient, so your speaking 55 degrees act when the car was mapped in the summer! ouft.
