pipe work
just been checking some pipe work on my car and i seen this pic on here and thought id use it i have a oil catch can fitted and pararrel fuel lines so i have deleted the charcole canister,steve
this is mine
this is mine
Last edited by batmanwrx; 07 September 2009 at 10:31 PM.
Trending Topics
#10
Its wrong mate the one on the throttle body goes to the fuel pressure regulator. On the mainfold from the left they are:-
X X X
Dump Valve Boost Controller Small pipe on the
and Pressure G Vapour Canister
X X X
Dump Valve Boost Controller Small pipe on the
and Pressure G Vapour Canister
#11
sorry that didnt turn out right
Far Left :- Dump Valve
2nd Left :- Boost Controller
Far Right:- Small pipe on the Vapour Canister near radiator
The one on the throttle body goes to the vac line on the pressure regulator
Hope this helps
Far Left :- Dump Valve
2nd Left :- Boost Controller
Far Right:- Small pipe on the Vapour Canister near radiator
The one on the throttle body goes to the vac line on the pressure regulator
Hope this helps
