2008-2010 2.5ltr Engine Failures

Notices
ScoobyNet General General Subaru Discussion

2008-2010 2.5ltr Engine Failures

Old 26 July 2010, 12:23 AM
  #61
rob84
Scooby Regular
iTrader: (5)

rob84's Avatar

Join Date: Jun 2006
Location: somewhere out there
Posts: 5,235
Default

Originally Posted by wigsworld View Post
Bit worried now, are the engine failures just on the sti's or are the wrx's at risk too?
Just the sti's as far as I'm aware

Last edited by rob84; 07 October 2010 at 12:40 AM.
rob84 is offline
Old 26 July 2010, 11:44 AM
  #62
Smiler-Wrx
Supporting Member

Join Date: May 2006
Location: United Kingdom
Posts: 186
Default

Originally Posted by rob84 View Post
Just the sti's the wrx has been fine no reported failures.

more prone are the 330s versions and the ppp'd cars
Are the cars ok after the recall flash update ?
Thanks in advance
Smiler-Wrx is offline
Old 26 July 2010, 11:58 AM
  #63
scooby L
Scooby Regular

scooby L's Avatar

Join Date: Feb 2003
Location: CHIPP'N HAM
Posts: 3,931
Default

The flash update removes the red line lean fuel issue that was causing the serious DET failures... BUT If you run these cars on crap fuel they will still have those issues and thus possible failure even with the flash update.

Mines been on V power since I got it, and I've had Duncan map it to that fuel... no failures and now on 27k

Last edited by scooby L; 26 July 2010 at 12:01 PM.
scooby L is offline
Old 26 July 2010, 12:13 PM
  #64
Littleted
Scooby Regular

Join Date: Oct 2009
Location: Leeds
Posts: 3,984
Default

Originally Posted by wigsworld View Post
Bit worried now, are the engine failures just on the sti's or are the wrx's at risk too?
ive just had first service on WRX-S and all ok so far 11k in

touch wood.

95 ron all the time, BUT due to move to 98 now
Littleted is offline
Old 26 July 2010, 01:03 PM
  #65
p.rite.sh
Scooby Regular

p.rite.sh's Avatar

Join Date: Feb 2010
Posts: 543
Default

Originally Posted by rob84 View Post
was on piston heads for starters someone had been filling up and tryed mapping there car and it wasnt having much luck so took a sample from mine to be tested no-one will accept responsibility for it

dont that mean shell should pay for the new block?

Jst as an FYI, my 2006 2.5 sti engine failed - 45k miles, new shortblock. went in several times to be looked at when there was "no problem" until it went pop
p.rite.sh is offline
Old 01 August 2010, 07:00 PM
  #66
Mrfastbaz
Scooby Regular

Join Date: Dec 2006
Location: England somewhere
Posts: 566
Default

add another one to the list

reg 57 plate 2.5 litre sti type uk with ppp fitted at factory, current ,mileage 12200 2 subaru services at 1 year and 2 years old recorded in service book, car purchased, in april 2010 by myself so have covered around 3000 miles mixed driving motorway and daily driving, use v power all the time from the local shell garage. this is the 2nd scoob i have owned so have a background in them always warmed up and given a couple of minutes to warm down currently in dealership awaiting replacement short engine under warranty
Mrfastbaz is offline
Old 01 August 2010, 07:08 PM
  #67
renny
Scooby Regular
iTrader: (2)

renny's Avatar

Join Date: Feb 2007
Location: England
Posts: 1,131
Default

Originally Posted by Mrfastbaz View Post
add another one to the list

reg 57 plate 2.5 litre sti type uk with ppp fitted at factory, current ,mileage 12200 2 subaru services at 1 year and 2 years old recorded in service book, car purchased, in april 2010 by myself so have covered around 3000 miles mixed driving motorway and daily driving, use v power all the time from the local shell garage. this is the 2nd scoob i have owned so have a background in them always warmed up and given a couple of minutes to warm down currently in dealership awaiting replacement short engine under warranty
1st 57 plate I've seen with the problem,just inside warranty period as well!!


There's going to be a few unhappy people as this is obviously going to keep happening outside of the warranty as well.
renny is offline
Old 01 August 2010, 07:56 PM
  #68
STEVECHAPS
Scooby Regular

Join Date: Mar 2000
Posts: 1,101
Question

Originally Posted by Mrfastbaz View Post
add another one to the list

reg 57 plate 2.5 litre sti type uk with ppp fitted at factory, current ,mileage 12200 2 subaru services at 1 year and 2 years old recorded in service book, car purchased, in april 2010 by myself so have covered around 3000 miles mixed driving motorway and daily driving, use v power all the time from the local shell garage. this is the 2nd scoob i have owned so have a background in them always warmed up and given a couple of minutes to warm down currently in dealership awaiting replacement short engine under warranty
What were the symptoms before failure please M8
STEVECHAPS is offline
Old 01 August 2010, 11:55 PM
  #69
Mrfastbaz
Scooby Regular

Join Date: Dec 2006
Location: England somewhere
Posts: 566
Default

just heard a slight knocking noise after running the car for about 10 minutes last wednesday. Came home and let the car tickover lifted the bonnet and could hear a slight rattle from the bottom end intermitantly. took it to the dealer carefully they revved it to about 4000 rpm for around 20 secs dropped it to tickover then blipped the throttle and there was the rattle loud and clear...at no time before this did i have any noise or any loss of power, oil use loss of water anything ...
Mrfastbaz is offline
Old 06 August 2010, 03:08 PM
  #70
RogerE
Scooby Regular

Join Date: Sep 1998
Posts: 82
Default

Oh dear.
Trading in my WR1 for a new STI tomorrow. I haven't been on scoobynet for some time and so had not seen this thread. I hope they have sorted the problem out for the last few STIs before the 2011 car comes out.
RogerE is offline
Old 06 August 2010, 03:23 PM
  #71
Butty
Scooby Regular
iTrader: (2)

Join Date: Oct 2000
Location: MY06 STi Spec D
Posts: 5,254
Default

Since a few 06/07 cars are being mentioned, I thought I'd add a piccy of mine when I stripped it down.
Symptoms were boost related coolant and bubbles to expansion tank with occasional over topping if I didn't pour the tank contents back to the header tank.
It never overheated.
I guess it started at about 38,000 miles and didn't change the engine until 43,000.

This is no.s 1 & 3 cylinders:




Note that the gaskets have gone at the same location. It was the same spot on the other two cylinders.
I'm presuming that the exhaust end head bolts worked their way loose?
Butty is offline
Old 06 August 2010, 07:30 PM
  #72
rob84
Scooby Regular
iTrader: (5)

rob84's Avatar

Join Date: Jun 2006
Location: somewhere out there
Posts: 5,235
Default

The Bolts dont work themselves loose, its the head itself that some how sinks in the middle, God only knows how it does it but seen it on a few because if you re torque the head bolts the cams become incredibly tight to try and turn
rob84 is offline
Old 06 August 2010, 08:12 PM
  #73
p.rite.sh
Scooby Regular

p.rite.sh's Avatar

Join Date: Feb 2010
Posts: 543
Default

Originally Posted by Butty View Post
Since a few 06/07 cars are being mentioned, I thought I'd add a piccy of mine when I stripped it down.
Symptoms were boost related coolant and bubbles to expansion tank with occasional over topping if I didn't pour the tank contents back to the header tank.
It never overheated.
I guess it started at about 38,000 miles and didn't change the engine until 43,000.

This is no.s 1 & 3 cylinders:




Note that the gaskets have gone at the same location. It was the same spot on the other two cylinders.
I'm presuming that the exhaust end head bolts worked their way loose?

apologies for my lack of knowledge, where are the gaskets? are they worn at the bottom of the circles?
p.rite.sh is offline
Old 06 August 2010, 09:24 PM
  #74
rob84
Scooby Regular
iTrader: (5)

rob84's Avatar

Join Date: Jun 2006
Location: somewhere out there
Posts: 5,235
Default

Bottom of the bores as circled in red mate, it blows hot exhaust gasses into the water jacket
rob84 is offline
Old 06 August 2010, 09:31 PM
  #75
VinceW
Scooby Regular

VinceW's Avatar

Join Date: Nov 2002
Location: Kent, England.
Posts: 252
Default

It is the pistons that fail on the hatch apparently, looks as if you have a different problem. still not a good advert for subaru though. is the car standard/modified or ppp?
VinceW is offline
Old 06 August 2010, 11:38 PM
  #76
p.rite.sh
Scooby Regular

p.rite.sh's Avatar

Join Date: Feb 2010
Posts: 543
Default

thanks Rob.
p.rite.sh is offline
Old 06 August 2010, 11:40 PM
  #77
rob84
Scooby Regular
iTrader: (5)

rob84's Avatar

Join Date: Jun 2006
Location: somewhere out there
Posts: 5,235
Default

Originally Posted by VinceW View Post
It is the pistons that fail on the hatch apparently, looks as if you have a different problem. still not a good advert for subaru though. is the car standard/modified or ppp?
Pistons that usually fail, and have had a couple of headgaskets go too

the engine above is from a hawkeye if i'm not mistaken
rob84 is offline
Old 07 August 2010, 03:27 PM
  #78
Hopper
Scooby Regular

Join Date: Dec 2009
Location: Sidcup, Kent
Posts: 43
Default

Sorry, just found this thread. I have a 2.0 WRX PPP, but have a stack of correspondence to and from IM and none of it helpful.
My car had done 36K miles with full Subaru history, the last service just 200miles prior to big-end failure.
The car was out of warranty, but I thought I would have a case for at least some help with the cost.
No joy and only tea and sympathy.
I tried the aforementioned Mr Hogg and the technical man, neither would accept any responsibility or offer any explanation or assurances.
I even wrote direct to Subaru in Japan. They just referred me back to IM.
Don't expect anything from them. If you think you have a valid case send everything by snail mail and recorded delivery.
Expect long pauses when nothing happens and then have to write to them again to demand a response.
This, I am afraid is normal service from IM over Subaru engine failures.
There are a lot of them, including brand new cars but IM deny there is even an issue.
If you get all the data together it would be very interesting to see it published here. I am convinced the problem is far greater than we all imagine.
I am not a scaremonger, but I would never buy another Subaru and this is my second car and bought new.
Hopper is offline
Old 07 August 2010, 09:02 PM
  #79
Butty
Scooby Regular
iTrader: (2)

Join Date: Oct 2000
Location: MY06 STi Spec D
Posts: 5,254
Default

Originally Posted by rob84 View Post
The Bolts dont work themselves loose, its the head itself that some how sinks in the middle, God only knows how it does it but seen it on a few because if you re torque the head bolts the cams become incredibly tight to try and turn
That explains why it was difficult to check the valve clearances. The cams were so difficult to rock.
I swapped to some ARP studs thinking it was the std bolts.

Are the cams going to wear badly if I've torqued down this central are of the heads?
So what was changed on later 2.5 heads to stop this?

Originally Posted by VinceW View Post
It is the pistons that fail on the hatch apparently, looks as if you have a different problem. still not a good advert for subaru though. is the car standard/modified or ppp?
It was rather modded 06 STi so not a good candidate for a warranty, although I did try.

Last edited by Butty; 07 August 2010 at 09:05 PM.
Butty is offline
Old 07 August 2010, 10:54 PM
  #80
Midlife......
Scooby Regular
iTrader: (2)

Join Date: Feb 2004
Posts: 11,584
Default

Hopper.... for a 2.0 liter is yours a Jap car ?

Shaun

PS Butty, if I've got my user names right it's Rob84 who is going to be dropping a 2.5 into my car.....along with your STi manifold which is in my hall as I speak

What plugs should I be using for the 2.5, I had NGK PFR7B's and then swapped them for ....memory fails.......BK8's when I had the meth injection...
Midlife...... is offline
Old 08 August 2010, 12:14 AM
  #81
Butty
Scooby Regular
iTrader: (2)

Join Date: Oct 2000
Location: MY06 STi Spec D
Posts: 5,254
Default

Shaun,
The plugs depend on the heads you use, so I'd keep to the plugs you already have.
If you ever use the 2.5 heads then its ILFR7H.
Butty is offline
Old 08 August 2010, 12:48 AM
  #82
Midlife......
Scooby Regular
iTrader: (2)

Join Date: Feb 2004
Posts: 11,584
Default

Nick

The plugs are a little tired I gues so I'll get some replacements........... just off to RCMS website and also look at an oil pump

What do you think I should get ?

Cheers

Shaun
Midlife...... is offline
Old 08 August 2010, 10:12 AM
  #83
Hopper
Scooby Regular

Join Date: Dec 2009
Location: Sidcup, Kent
Posts: 43
Default

Originally Posted by Midlife...... View Post
Hopper.... for a 2.0 liter is yours a Jap car ?
No, I bought mine new in Sept '04. All the servicing was by Main dealers and on the button.

The experience has put me off ever buying another 'ru.

You think you are doing everything right, according to the manufacturers recommendations then the engine fails 200 miles after a major service.

And then IM say that it's just one of those things and that's that.

In the end they told me that if I wrote to them again about it they would not answer.

They never admitted there was a problem, suggested what could have caused it or were able to give any assurances that it would not happen again anytime.

When I first returned the car to the dealers I was told by the mechanic there that he had "done hundreds of them" when asked about replacing the crank and big ends. Possibly an exaggeration. but you get the idea.

Another told me that his mate who worked at a dealership in Chelmsford somewhere had four similar jobs there awaiting parts and one was an almost new car with 2,000 miles on the clock.

The worrying thing for me though, is that despite a number of theories nobody can say definitively what causes the problems and so you feel like you are driving a bloody time-bomb.

And yet all the time there are people out there with starship mileage and huge power outputs who have no problems whatever.

It leaves you thinking that maybe IM are correct in their belief that it is just one of those things.

Maybe we just got Friday afternoon cars . . . .
Hopper is offline
Old 08 August 2010, 02:49 PM
  #84
rob84
Scooby Regular
iTrader: (5)

rob84's Avatar

Join Date: Jun 2006
Location: somewhere out there
Posts: 5,235
Default

Originally Posted by Butty View Post
That explains why it was difficult to check the valve clearances. The cams were so difficult to rock.
I swapped to some ARP studs thinking it was the std bolts.

Are the cams going to wear badly if I've torqued down this central are of the heads?
So what was changed on later 2.5 heads to stop this?


Nothing as far as i'm aware has been changed on the heads, the only real way is to skim the head a little if its possible to level it back out as when you torque it down it pulls the middle in if its not perfectly flat the hatches suffer the same problem, I got lucky with mine as it had only just blown on the way home & dumped all its coolant out so filled it right back up with hot water so no long term damage done.

If you reassemble the cams into a head thats sunk so to speak it will happen were the cams will seize up if they were very tight to turn. I saw one that only got 3 miles before it shattered the cam pulleys. Young lad wasnt aware how much damage could be done.


Shaun you have the right person lol & the Plugs I use in my 2.5 are LFR7AIX Ngk's. the 2.5 heads have a longer reach plug fitted to them were'as the 2.0 just have short plugs fitted

Last edited by rob84; 08 August 2010 at 02:51 PM.
rob84 is offline
Old 10 August 2010, 04:13 PM
  #85
Butty
Scooby Regular
iTrader: (2)

Join Date: Oct 2000
Location: MY06 STi Spec D
Posts: 5,254
Default

Originally Posted by rob84 View Post
Nothing as far as i'm aware has been changed on the heads, the only real way is to skim the head a little if its possible to level it back out as when you torque it down it pulls the middle in if its not perfectly flat the hatches suffer the same problem, I got lucky with mine as it had only just blown on the way home & dumped all its coolant out so filled it right back up with hot water so no long term damage done.

If you reassemble the cams into a head thats sunk so to speak it will happen were the cams will seize up if they were very tight to turn. I saw one that only got 3 miles before it shattered the cam pulleys. Young lad wasnt aware how much damage could be done.


Shaun you have the right person lol & the Plugs I use in my 2.5 are LFR7AIX Ngk's. the 2.5 heads have a longer reach plug fitted to them were'as the 2.0 just have short plugs fitted
I had the heads lightly skimmed anyway as the HGs must have flapped a bit when leaking and dug slightly into the heads.
Butty is offline
Old 16 August 2010, 08:54 AM
  #86
VinceW
Scooby Regular

VinceW's Avatar

Join Date: Nov 2002
Location: Kent, England.
Posts: 252
Default

Has the re-flash stopped the engine failures in the hatch or is it still happening does anybody know?
VinceW is offline
Old 16 August 2010, 04:43 PM
  #87
mickp
Scooby Regular
iTrader: (1)

mickp's Avatar

Join Date: Mar 2005
Location: North West
Posts: 1,395
Default

Originally Posted by VinceW View Post
Has the re-flash stopped the engine failures in the hatch or is it still happening does anybody know?
The flash may have helped reduce the number of failures but it has certainly not cured the root problem (pistons)
mickp is offline
Old 16 August 2010, 08:43 PM
  #88
TonyBurns
Scooby Regular
iTrader: (3)

TonyBurns's Avatar

Join Date: Aug 2000
Location: 1600cc's of twin scroll fun :)
Posts: 25,564
Default

Yup the pistons are of a bad design, then again the engine wasnt meant for the Impreza, sort of an oversight, though if it goes pop again and your dealer is nice, you may get them to put some decent ones in

Tony
TonyBurns is offline
Old 16 August 2010, 08:57 PM
  #89
joz8968
Scooby Regular
iTrader: (13)

joz8968's Avatar

Join Date: Aug 2006
Location: Indochina......hiding inside a bowl of rice
Posts: 23,699
Default

Can anyone give a scientific explanation for the reason why the 2.5's pistons cause these failures?
joz8968 is offline
Old 16 August 2010, 09:20 PM
  #90
andythejock01wrx
Orange Club

Join Date: Jun 2006
Location: Edinburgh (ish)
Posts: 8,091
Default

Nope, but I like your booby pic!
andythejock01wrx is offline

Thread Tools
Search this Thread
Quick Reply: 2008-2010 2.5ltr Engine Failures


Contact Us Archive Advertising Cookie Policy Privacy Statement Terms of Service

© 2018 MH Sub I, LLC dba Internet Brands

We are a participant in the Amazon Services LLC Associates Program, an affiliate advertising program designed to provide a means for us to earn fees by linking to Amazon.com and affiliated sites.
