apexi Pfc setting to adjust fuel on overrun
22 October 2005, 11:10 PM
#31
Scooby Regular
iTrader: (2)
Join Date: Mar 2001
Location: Here and there
Posts: 8,353
Likes: 0
Received 0 Likes
on
0 Posts
Originally Posted by Andy.F
I find the best flames come from zero degrees of timing on the top row and maximum of 1.496 fuel (its still not a lot of IDC)
Only adjust down to around 2400rpm though as you can drop into the 2nd top row during very light cruise at lower rpm and it will start to interpolate into the top row with some rather odd results
You need a hot exhaust for best results.......
Andy (I promise to grow up soon )
Only adjust down to around 2400rpm though as you can drop into the 2nd top row during very light cruise at lower rpm and it will start to interpolate into the top row with some rather odd results
You need a hot exhaust for best results.......
Andy (I promise to grow up soon
)
still flaming spendidly thanks Andy
23 October 2005, 08:34 PM
#32
Scooby Regular
Join Date: May 2002
Posts: 382
Likes: 0
Received 0 Likes
on
0 Posts
Originally Posted by ScoobyDuck
it was all in tounge and cheek mate this is ment to be fun
so was it cells N6-P1 -> N20-P1 that you changed?
they should have been somewhere in the region of 40-45 degrees originally ?
if the car smelt of fuel it could have been hitting those cells, but i highly doubt it as it would have to be reving to 2800+ or just below.
best thing to try is to go onto map watch and see what cells you get when you do rev it. this can also be used to see where its going when you are on overrun.
i have found that you do need to open the throttle a little (just press it) if you havent got the fuel cut off turned up, so you need the ecu to throw some fuel in.
try looking at the map watch and see if you are in the right area
Steve
this is ment to be fun so was it cells N6-P1 -> N20-P1 that you changed?
they should have been somewhere in the region of 40-45 degrees originally ?
if the car smelt of fuel it could have been hitting those cells, but i highly doubt it as it would have to be reving to 2800+ or just below.
best thing to try is to go onto map watch and see what cells you get when you do rev it. this can also be used to see where its going when you are on overrun.
i have found that you do need to open the throttle a little (just press it) if you havent got the fuel cut off turned up, so you need the ecu to throw some fuel in.
try looking at the map watch and see if you are in the right area
Steve
6-20 was what i changed op row:
IGN was 44 degree
Will post orginal INJ sett 2moro but when i change 6-20 to 1.496 thats wen everything went wrong,idle was all over the place and car was spluttering bad
Went for a run and it was missing real bad too.
Since then i have reset to orginal settings and all i can say is adjusting the top row definently alters the running of the car as 2day i have been out experimenting and adding and reducing settings in these cells change boost,misfire and idle.
The only other possible conclution would be that as i increased the fueling it has fouled the plugs making the car to runlike a bag of ****e
23 October 2005, 09:14 PM
#33
Scooby Regular
iTrader: (1)
Join Date: Oct 2001
Location: South East
Posts: 1,300
Likes: 0
Received 0 Likes
on
0 Posts
oh dear
cant say why that could happen as it should only ever get there on low load, like off throttle.
have a look on map trace and see if you are getting there. but i think you'd best keep it how it was if it does that !
plugs...a few WOT blasts should sort them out
cant say why that could happen as it should only ever get there on low load, like off throttle.
have a look on map trace and see if you are getting there. but i think you'd best keep it how it was if it does that !
plugs...a few WOT blasts should sort them out
04 November 2005, 07:25 PM
#36
Scooby Regular
Join Date: Sep 2002
Posts: 187
Likes: 0
Received 0 Likes
on
0 Posts
Originally Posted by ScoobyDuck
what ? fuel cut off ? about 950
setting it back to normal as i never got any flames or bangs
all i got was the car smelling of petrol most of the time and running rough at low speeds like plugs fouling
Last edited by shocker; 04 November 2005 at 07:28 PM.
04 November 2005, 09:04 PM
#37
Scooby Regular
Join Date: May 2002
Posts: 382
Likes: 0
Received 0 Likes
on
0 Posts
Originally Posted by ScoobyDuck
oh dear
cant say why that could happen as it should only ever get there on low load, like off throttle.
have a look on map trace and see if you are getting there. but i think you'd best keep it how it was if it does that !
plugs...a few WOT blasts should sort them out
cant say why that could happen as it should only ever get there on low load, like off throttle.
have a look on map trace and see if you are getting there. but i think you'd best keep it how it was if it does that !
plugs...a few WOT blasts should sort them out
Hows does the maptrace work,can not seem to see any way of reading it,can you point me in the right direction
04 November 2005, 09:19 PM
#38
Scooby Regular
iTrader: (2)
Join Date: Mar 2001
Location: Here and there
Posts: 8,353
Likes: 0
Received 0 Likes
on
0 Posts
AndyF mapped mine to do this and its very effective and far less chav than a flamer kit.Just dont get it mapped when theres a lot of white van men about on the road,as we found out whilst mapping mine,i got all sorts of abuse (i blame Andy)
04 November 2005, 09:20 PM
#39
Scooby Regular
iTrader: (1)
Join Date: Oct 2001
Location: South East
Posts: 1,300
Likes: 0
Received 0 Likes
on
0 Posts
when you go in to monitor, choose the bottom option, map trace (IIRC)
it then show you what cells you are using at the time.
i think the right button turns on ghosting - which leaves the cell black where you have been.
basically , if you are on overrun, note what cell you are in. its a bit small to see, but you can freeze it too - cant remember which button, just press away
happy playing
it then show you what cells you are using at the time.
i think the right button turns on ghosting - which leaves the cell black where you have been.
basically , if you are on overrun, note what cell you are in. its a bit small to see, but you can freeze it too - cant remember which button, just press away
happy playing
02 March 2008, 05:55 PM
#40
been meaning to do this for ages and finally got off my **** sat to do this and have had no problems with idle and running, but alas no pops! but i do have the ""chavy"" flamer kit on, and when this is on it does make it easier for flames!!!
watched the map tracer and it hardly ever gets into line 1 so could this be why im not getting the pops?? it goes in the other lines then on deccelerating goes into line one for one cell then stays in line 2. should this be happening???
steve
watched the map tracer and it hardly ever gets into line 1 so could this be why im not getting the pops?? it goes in the other lines then on deccelerating goes into line one for one cell then stays in line 2. should this be happening???
steve
03 March 2008, 08:17 PM
#42
Scooby Regular
Join Date: Jun 2003
Location: Founder of surreyscoobies.co.uk
Posts: 2,889
Likes: 0
Received 0 Likes
on
0 Posts
Mine is just setup so the F/Cut is set to 5500 on the top setting, the normal fuel cut is running at 1500rpm.
Timing has also been reduced on over run..
AP
Timing has also been reduced on over run..
AP
03 March 2008, 08:32 PM
#43
Subaru Tuning Specialist
Join Date: Jun 2002
Location: 7.74 @179 mph 1/4 mile - road legal
Posts: 6,654
Likes: 0
Received 1 Like
on
1 Post
On some cars you need to change the maf scaling so it lands in row 1 on overrun, sometimes its the BOV causing higher flow, tighten that a bit if you have an adjustable one.
As Andy mentions above, you need to increase your fuel cut recovery point too.
Andy
As Andy mentions above, you need to increase your fuel cut recovery point too.
Andy
03 March 2008, 10:29 PM
#44
hi, thanks.
its for a V4 type r. ive got two F/c settings originaly 950 and 1050 so changed both to 5000. and as well as following the other settings for ign and inj. BOV is fixed forge. it goes into row 1 in cell 6 or 7 i think. bit hard to look while driving!!!! then goes bakc into row2
its for a V4 type r. ive got two F/c settings originaly 950 and 1050 so changed both to 5000. and as well as following the other settings for ign and inj. BOV is fixed forge. it goes into row 1 in cell 6 or 7 i think. bit hard to look while driving!!!! then goes bakc into row2
07 March 2008, 08:40 AM
#49
Subaru Tuning Specialist
Join Date: Jun 2002
Location: 7.74 @179 mph 1/4 mile - road legal
Posts: 6,654
Likes: 0
Received 1 Like
on
1 Post
If you don't have access to the scaling menus, try dropping the timing in row2 above say 2400rpm, the risk here is that you land in that row during normal driving which would lead to hesitation.
07 March 2008, 05:35 PM
#51
thanks for repklies.
i make sure ive written down the original settings so if there is any problems then just go bakc to normal!!! i only drive at weekends when(hopefully) no traffic about, so just fun driving to be had!!!! :-)
ill try the row two settings and see what happens
thanks steve
i make sure ive written down the original settings so if there is any problems then just go bakc to normal!!! i only drive at weekends when(hopefully) no traffic about, so just fun driving to be had!!!! :-)
ill try the row two settings and see what happens
thanks steve
18 March 2008, 09:15 PM
#52
Scooby Regular
Join Date: May 2007
Posts: 36
Likes: 0
Received 0 Likes
on
0 Posts
any 1 else tried this and have it working good
what kind of revs do you have to be into ...as mine is just getting run in but would like some popping banging on overun will it be safe to do on run in ??
what kind of revs do you have to be into ...as mine is just getting run in but would like some popping banging on overun will it be safe to do on run in ??
29 October 2008, 11:09 AM
#53
Andy F worte something about the heaterswitch and making the pops and bangs availaible by pressing it... has anybody managed to do this?
I think it´s only available by Ecutek to make the second map running.
I think it´s only available by Ecutek to make the second map running.
29 October 2008, 12:02 PM
#54
Scooby Regular
iTrader: (15)
Join Date: Jul 2001
Location: Portsmouth
Posts: 8,606
Likes: 0
Received 0 Likes
on
0 Posts
Markus,
The heater switch thing is on ECUTEK as you say.
You could use the air con to make a powerFC pop and bang I'm sure as there are two settings on it for air con and normal.
So you could have the fuel coming in earlier with the air con on, but you don't have switchable maps so the timing would have to be the same regardless.
The heater switch thing is on ECUTEK as you say.
You could use the air con to make a powerFC pop and bang I'm sure as there are two settings on it for air con and normal.
So you could have the fuel coming in earlier with the air con on, but you don't have switchable maps so the timing would have to be the same regardless.
29 October 2008, 01:41 PM
#56
Scooby Regular
iTrader: (1)
Join Date: Aug 2005
Location: Manchester ish
Posts: 18,547
Likes: 0
Received 0 Likes
on
0 Posts
with the aircon, I think the engine sees more load so will go to different rows/cells in the map. There is a commander setting that does something re the aircon, think this may just be the fuel cut thing. If it is, just change the fuel cut on that setting and if you want the pops and bangs just press in the aircon button (you will still need to adjust the top 2 rows though).
30 October 2008, 06:05 PM
#58
* So under [Settings] > [Rev/Idle], you'd need to set [F/C A/C] to 5000rpm, yes?
* Then under [Settings] > [IGN Map] alter the top 2 rows...
Row 1:
20, 35, 38, 40, 42, 00, 00, 00, 00, 00...
...00, 00, 00, 00, 00, 00, 00, 00, 00, 00.
Row 2:
20, 35, 38, 40, 42, 43, 44, 44, 44, 45...
...45, 45, 45, 45, 45, 45, 45, 45, 45, 45.
* Then under [Settings] > [INJ Map] alter the top 2 rows...
Row 1:
1.000, 0.980, 0.977, 0.973, 0.961, 1.496, 1.496, 1.496, 1.496, 1.496...
...1.496, 1.496, 1.496, 1.496, 1.496, 1.496, 1.496, 1.496, 1.496, 1.496.
Row 2:
1.039, 0.980, 0.977, 0.973, 0.961, 0.961, 0.938, 0.922, 0.938, 0.977...
...1.000, 1.000, 1.000, 1.000, 1.000, 1.000, 1.000, 1.000, 1.000, 1.000.
...As pointed out earlier. So when you switch the A/C button on, shenanigans can begin?! Is this correct?
* Then under [Settings] > [IGN Map] alter the top 2 rows...
Row 1:
20, 35, 38, 40, 42, 00, 00, 00, 00, 00...
...00, 00, 00, 00, 00, 00, 00, 00, 00, 00.
Row 2:
20, 35, 38, 40, 42, 43, 44, 44, 44, 45...
...45, 45, 45, 45, 45, 45, 45, 45, 45, 45.
* Then under [Settings] > [INJ Map] alter the top 2 rows...
Row 1:
1.000, 0.980, 0.977, 0.973, 0.961, 1.496, 1.496, 1.496, 1.496, 1.496...
...1.496, 1.496, 1.496, 1.496, 1.496, 1.496, 1.496, 1.496, 1.496, 1.496.
Row 2:
1.039, 0.980, 0.977, 0.973, 0.961, 0.961, 0.938, 0.922, 0.938, 0.977...
...1.000, 1.000, 1.000, 1.000, 1.000, 1.000, 1.000, 1.000, 1.000, 1.000.
...As pointed out earlier. So when you switch the A/C button on, shenanigans can begin?!
Is this correct?
Last edited by joz8968; 30 October 2008 at 06:26 PM.
30 October 2008, 06:36 PM
#59
Scooby Regular
Join Date: Feb 2003
Location: Zed Ess Won Hay Tee
Posts: 21,611
Likes: 0
Received 0 Likes
on
0 Posts
yes its fuel cut return
when you back off the throttle it does not add any fuel until a predetermined point,
this point can be adjusted 1. with the aircon on, 2. with the aircon off
after playing with the 1.49 fuel rows and fuel cut return and i can tell you that i got more pops and crackles with stock fuel settings, but with them set to 1.49 i got less, but they seamed to "save themselves up" and come as one big one instead, it also made my back bumper go all burnt and i had to machine polish it back off
try keeping your fuel the same, retard the ignition to zero in the top rows, and adjust the fuel cut recovery up to about 5/6k
you need your exhaust hot, if they are not big enough (pops bangs)for you then change the fuel rows.
be aware that i once thought my exhaust had fell off due to the massive boom lmfao
some advice
set the fuel recovery "mode" to enable when the aircon is ON
i set it to happen when it is OFF and while i always drive around with the aircon switched on, i did not realise that the system is constantly stopping and starting, i assume the apexi is only bothered about the compressor working, not weather or not the button is pressed in.
i drove for 2 weeks with my system ON (but had a leak so the compressor was not working) and managed to do in a tank of fuel in 160miles pmsl
when you back off the throttle it does not add any fuel until a predetermined point,
this point can be adjusted 1. with the aircon on, 2. with the aircon off
after playing with the 1.49 fuel rows and fuel cut return and i can tell you that i got more pops and crackles with stock fuel settings, but with them set to 1.49 i got less, but they seamed to "save themselves up" and come as one big one instead, it also made my back bumper go all burnt and i had to machine polish it back off
try keeping your fuel the same, retard the ignition to zero in the top rows, and adjust the fuel cut recovery up to about 5/6k
you need your exhaust hot, if they are not big enough (pops bangs)for you then change the fuel rows.
be aware that i once thought my exhaust had fell off due to the massive boom lmfao
some advice
set the fuel recovery "mode" to enable when the aircon is ON
i set it to happen when it is OFF and while i always drive around with the aircon switched on, i did not realise that the system is constantly stopping and starting, i assume the apexi is only bothered about the compressor working, not weather or not the button is pressed in.
i drove for 2 weeks with my system ON (but had a leak so the compressor was not working) and managed to do in a tank of fuel in 160miles pmsl
