99greenwagon

iTrader: (39)

hi,im asking for a favour, and i know its a pain in the ****,but sometime soon my "wrx" boot sticker is going to arrive for my v4 sti type r. i now have the job of fitting it in the correct position and straight!
anyone that has the big wrx boot sticker on their sti will be able to give me exact measurements of where it is positioned......for anyone that can be arsed anyway!
i would gratefully appriciate these measurements as just looking at an image and eyeing it up just aint good enough! thanks in advance.

99greenwagon

iTrader: (39)

its this one,im assuming it goes dead centre from left to right,but what about up and down?

99greenwagon

iTrader: (39)

alcazar

iTrader: (2)

Looking at that photo, it would appear that the WRX is centred on the bootlock?

99greenwagon

iTrader: (39)

or a fraction higher perhaps? this is why i could do with some measurements as i really dont want to put it on pissed?

awdx4

The WRX part of the logo appears very much in the centre of the section of boot which is below the detail line shaped into the boot. If you look at the lower edge of the boot and take a line from each bottom corner of the boot, the bit that is between the rear lights, straight up so you make a rectangle of that surface then strike a line diagonally from each corner you'll have that centre point. Do the same with the WRX part of the logo, then measure to it upper edge and transfer that measurement to the boot and strike a line which will indicate the top edge of the logo. Getting it central from side to side is simple after that.

Tim

99greenwagon

iTrader: (39)

thanks tim.

awdx4

No worries mate, I hope to see lots of pics of the steps of your getting the car how you want it. They do become the subject of many hours of thought ;-) the missus reckons even my farts burble since I've tinkering with mine.

all the best

Tim

99greenwagon

iTrader: (39)
