Heated Mirror Failed
#1
Scooby Regular
Thread Starter
Join Date: May 2018
Location: North East
Posts: 67
Likes: 0
Received 0 Likes
on
0 Posts
Heated Mirror Failed
Hi All,
Was looking for some help on troubleshooting/fixing my passenger side wing mirror on my 2006 WRX Hawkeye which has stopped heating, the driver's side mirror is heating and defrosting fine. From what I've looked up there is only one fuse for both wing mirror heaters so it shouldn't be a fuse issue. Any help with knowing which replacement parts may be required would be great or is it easier to just get a replacement wing mirror?
Cheers.
Was looking for some help on troubleshooting/fixing my passenger side wing mirror on my 2006 WRX Hawkeye which has stopped heating, the driver's side mirror is heating and defrosting fine. From what I've looked up there is only one fuse for both wing mirror heaters so it shouldn't be a fuse issue. Any help with knowing which replacement parts may be required would be great or is it easier to just get a replacement wing mirror?
Cheers.
#2
Scooby Regular
If all other functions are working it may need a new mirror glass with element or a wire has broken/ become disconnected.
Last edited by Don Clark; 30 October 2019 at 11:07 AM.
#4
Scooby Regular
Thread Starter
Join Date: May 2018
Location: North East
Posts: 67
Likes: 0
Received 0 Likes
on
0 Posts
Similar to this:
#5
Scooby Regular
Thread Starter
Join Date: May 2018
Location: North East
Posts: 67
Likes: 0
Received 0 Likes
on
0 Posts
or would it be similar to this thread on a classic impreza?
https://www.scoobynet.com/technical-...sassemble.html
https://www.scoobynet.com/technical-...sassemble.html
#6
Scooby Regular
From what I've read I should be able to remove the glass from the mirror assembly by tilting it back and using a flat head screwdriver to release a clip? This would release the platform the mirror adheres, allowing me to seperate the glass away from the car?
Similar to this: https://www.youtube.com/watch?v=mjYPsYfwqHk
Similar to this: https://www.youtube.com/watch?v=mjYPsYfwqHk
or would it be similar to this thread on a classic impreza?
https://www.scoobynet.com/technical-...sassemble.html
https://www.scoobynet.com/technical-...sassemble.html
#7
Scooby Regular
Thread Starter
Join Date: May 2018
Location: North East
Posts: 67
Likes: 0
Received 0 Likes
on
0 Posts
Had a chance to take a look at the mirror, there appears to be a bezel/frame over the glass which I'm assuming is removed before I can heat and remove the glass. Any idea on the best way to remove this?
Trending Topics
#8
Scooby Regular
The bezel is what holds the glass in and is what you heat up to soften and lever out the glass
here are some further pictures
https://forums.sidc.co.uk/topic/1662...omment-1504053
here are some further pictures
https://forums.sidc.co.uk/topic/1662...omment-1504053
#10
Scooby Regular
#11
Scooby Regular
Thread Starter
Join Date: May 2018
Location: North East
Posts: 67
Likes: 0
Received 0 Likes
on
0 Posts
I copied the part code again after putting it into eBay, I think it may have auto-corrected it for a similar part name and didn't realise when I pasted it into my post.
Hopefully, it's not an expensive part.
Hopefully, it's not an expensive part.
#12
Scooby Regular
Thread Starter
Join Date: May 2018
Location: North East
Posts: 67
Likes: 0
Received 0 Likes
on
0 Posts
Just rang a Subaru Dealership and got quoted £80 for the part, special order from Japan, payment up front and no refunds. Might be worth looking at breakers for a complete wing mirror? or just get a can of de-icer
#13
Scooby Regular
Unfortunately not much cheaper from Amayama or Partsouq, importing from the UAE (about same price from Japan)
