disable ABS on a classic, easy or hard
18 October 2010, 04:21 PM
#1
Scooby Regular
Thread Starter
iTrader: (6)
Join Date: Feb 2010
Location: north of the south border
Posts: 4,510
Likes: 0
Received 0 Likes
on
0 Posts
disable ABS on a classic, easy or hard
until i get around to fixing the shot senser can i remove the fuse from my abs unit to disable it, will it cause any problems and will the warning light go off the dash, please note its a 95 calssic wrx,.
18 October 2010, 05:06 PM
#6
Scooby Regular
iTrader: (3)
Join Date: Aug 2000
Location: 1600cc's of twin scroll fun :)
Posts: 25,565
Likes: 0
Received 2 Likes
on
2 Posts
Its illegal (again) which means your insurance is invalid.
Really?
where do you get that amazing fact from
As I have said, its illegal to do, have an accident and your really screwed!
Now why dont you just go and buy a sensor and fix it? easy as pie
Tony
so are 99% of all insurance policies on scoobs but who cares??????
where do you get that amazing fact from As I have said, its illegal to do, have an accident and your really screwed!
Now why dont you just go and buy a sensor and fix it? easy as pie
Tony
18 October 2010, 05:27 PM
#7
Scooby Regular
Thread Starter
iTrader: (6)
Join Date: Feb 2010
Location: north of the south border
Posts: 4,510
Likes: 0
Received 0 Likes
on
0 Posts
Trending Topics
18 October 2010, 05:34 PM
#8
have you declared your decat or your air filter maybe a dump valve, you well know that no one does thus rendering policies void, as clearly bloody stated once i get a frikin chance i will buy a sensor and swap it , now can you answer the dammmmmm question if not dont post!!!!!!!!!!!!!
Don't take this the wrong way, but only a fool would not openly declare modifications
Because as stated - technically it declares your policy null and void.
As for is it safe to do - haven't got a clue.
Last edited by urban; 18 October 2010 at 05:36 PM.
18 October 2010, 05:37 PM
#9
Scooby Regular
Thread Starter
iTrader: (6)
Join Date: Feb 2010
Location: north of the south border
Posts: 4,510
Likes: 0
Received 0 Likes
on
0 Posts
why the frikin hell cant anyone just answer the first question why do you always end up chatting balllllsssss for hours about something you do not care 2 monkeys about,.
18 October 2010, 05:39 PM
#10
Never tried it on an impreza but usually if you remove the fuse it will register as a fault and light will stay on.
Not sure re the legality. All I know is if the car is fitted with abs then it must be functional but you are permitted to remove the abs fully.
Not sure re the legality. All I know is if the car is fitted with abs then it must be functional but you are permitted to remove the abs fully.
18 October 2010, 05:49 PM
#11
Scooby Regular
Thread Starter
iTrader: (6)
Join Date: Feb 2010
Location: north of the south border
Posts: 4,510
Likes: 0
Received 0 Likes
on
0 Posts
sounds plausable, i cant see it doing any damage to anything just the annoying light staying on,. is there a simple way to check which sensor is faulty
18 October 2010, 05:55 PM
#12
Scooby Regular
iTrader: (1)
Join Date: May 2010
Location: Farnham, Surrey
Posts: 173
Likes: 0
Received 0 Likes
on
0 Posts
I thought if a sensor was faulty then the ABS wont work anyway, it'll throw up the fault code and disable the system?
You havent said which model you have, but on the classics there should be a black block connector under the dash with a single black wire taped to it - maybe higher up. Connect the black wire to hole 6 of the connector, turn on the ignition and the code will flash up.
ABS DTC list
11 – Start Code, DTC is shown after start code, Only start code is shown in normal condition
Abnormal ABS sensor, open circuit or voltage too high
21 – front right ABS sensor
23 – front left ABS sensor
25 – rear right ABS sensor
27 – rear left ABS sensor
Abnormal ABS sensor, abnormal ABS sensor signal
22 – front right ABS sensor
24 – front left ABS sensor
26 – rear right ABS sensor
28 – rear left ABS sensor
29 – any one of four
Abnormal solenoid valve circuits in ABS control module and hydraulic unit
31 – Front right inlet valve
32 – Front right outlet valve
33 – Front left inlet valve
34 – Front left outlet valve
35 – Rear right inlet valve
36 – Rear right outlet valve
37 – Rear left inlet valve
38 – Rear left outlet valve
41 – Abnormal ABS control module
42 – Source voltage is abnormal
44 – A combination of AT control abnormal
51 – Abnormal valve relay
52 – Abnormal motor and/or motor relay
54 – Abnormal stop light switch
56 – Abnormal G sensor output voltage
You havent said which model you have, but on the classics there should be a black block connector under the dash with a single black wire taped to it - maybe higher up. Connect the black wire to hole 6 of the connector, turn on the ignition and the code will flash up.
ABS DTC list
11 – Start Code, DTC is shown after start code, Only start code is shown in normal condition
Abnormal ABS sensor, open circuit or voltage too high
21 – front right ABS sensor
23 – front left ABS sensor
25 – rear right ABS sensor
27 – rear left ABS sensor
Abnormal ABS sensor, abnormal ABS sensor signal
22 – front right ABS sensor
24 – front left ABS sensor
26 – rear right ABS sensor
28 – rear left ABS sensor
29 – any one of four
Abnormal solenoid valve circuits in ABS control module and hydraulic unit
31 – Front right inlet valve
32 – Front right outlet valve
33 – Front left inlet valve
34 – Front left outlet valve
35 – Rear right inlet valve
36 – Rear right outlet valve
37 – Rear left inlet valve
38 – Rear left outlet valve
41 – Abnormal ABS control module
42 – Source voltage is abnormal
44 – A combination of AT control abnormal
51 – Abnormal valve relay
52 – Abnormal motor and/or motor relay
54 – Abnormal stop light switch
56 – Abnormal G sensor output voltage
Last edited by deepy; 18 October 2010 at 06:00 PM.
18 October 2010, 06:03 PM
#13
What symptoms are you getting other than the abs light?
Or use the info I've just seen above lol!
Last edited by cazyp; 18 October 2010 at 06:05 PM.
18 October 2010, 06:16 PM
#14
Scooby Regular
iTrader: (3)
Join Date: Aug 2000
Location: 1600cc's of twin scroll fun :)
Posts: 25,565
Likes: 0
Received 2 Likes
on
2 Posts
have you declared your decat or your air filter maybe a dump valve, you well know that no one does thus rendering policies void, as clearly bloody stated once i get a frikin chance i will buy a sensor and swap it , now can you answer the dammmmmm question if not dont post!!!!!!!!!!!!!
) on BOTH my STI's thanks.As yours has ABS, your not allowed by LAW to disable it, doing so will make your car un roadworthy thus also invalidating your insurance (as you have removed/tampered with the braking system), so your NOT ALLOWED TO DO IT FOOKWIT!!! or did you not understand what you have been told?
Tony
18 October 2010, 06:37 PM
#15
Scooby Regular
Thread Starter
iTrader: (6)
Join Date: Feb 2010
Location: north of the south border
Posts: 4,510
Likes: 0
Received 0 Likes
on
0 Posts
I have fully declared everything (dont use crappy "dump valves" the standard re circ is more than sufficient ) on BOTH my STI's thanks.
As yours has ABS, your not allowed by LAW to disable it, doing so will make your car un roadworthy thus also invalidating your insurance (as you have removed/tampered with the braking system), so your NOT ALLOWED TO DO IT FOOKWIT!!! or did you not understand what you have been told?
Tony
) on BOTH my STI's thanks.As yours has ABS, your not allowed by LAW to disable it, doing so will make your car un roadworthy thus also invalidating your insurance (as you have removed/tampered with the braking system), so your NOT ALLOWED TO DO IT FOOKWIT!!! or did you not understand what you have been told?
Tony
18 October 2010, 06:43 PM
#16
18 October 2010, 07:09 PM
#21
happens all the time on here ,ask a question and you have to go all round the houses for an answer
18 October 2010, 10:22 PM
#28
Scooby Regular
iTrader: (3)
Join Date: Aug 2000
Location: 1600cc's of twin scroll fun :)
Posts: 25,565
Likes: 0
Received 2 Likes
on
2 Posts
See you the 23rd oct at prosport for the rolling road day, i will be there if you have the ***** to turn up, and yes, the advice that i gave is correct, you on the other hand seem to want to drive an unservicable vehicle on the road with all the other road users, bravo, your a total fcukwhit for doing so
Tony
18 October 2010, 10:26 PM
#29
Scooby Regular
Thread Starter
iTrader: (6)
Join Date: Feb 2010
Location: north of the south border
Posts: 4,510
Likes: 0
Received 0 Likes
on
0 Posts
Jeez, total chopper who gives scoob owerns a bad name
See you the 23rd oct at prosport for the rolling road day, i will be there if you have the ***** to turn up, and yes, the advice that i gave is correct, you on the other hand seem to want to drive an unservicable vehicle on the road with all the other road users, bravo, your a total fcukwhit for doing so
Tony
See you the 23rd oct at prosport for the rolling road day, i will be there if you have the ***** to turn up, and yes, the advice that i gave is correct, you on the other hand seem to want to drive an unservicable vehicle on the road with all the other road users, bravo, your a total fcukwhit for doing so
Tony
18 October 2010, 10:35 PM
#30
Scooby Regular
iTrader: (3)
Join Date: Aug 2000
Location: 1600cc's of twin scroll fun :)
Posts: 25,565
Likes: 0
Received 2 Likes
on
2 Posts
LOL, see you there then?
Still you dont seem to get it do you?
Suppose some people dont have any idea's or even bother with other road users safety just ones that dont bother with consequences of their actions due to driving a defective vehicle
And your the only one with the attitude, think you need to look a bit closer to home (oh and do you have insurance or do you flaunt that too?)
Tony
Still you dont seem to get it do you?
Suppose some people dont have any idea's or even bother with other road users safety
just ones that dont bother with consequences of their actions due to driving a defective vehicle And your the only one with the attitude, think you need to look a bit closer to home (oh and do you have insurance or do you flaunt that too?)
Tony
