Intercooler pipe beading tool

Thread Tools

Search this Thread

Old Mar 31, 2015 | 04:12 PM
  #1
Timmay Zoom Zoom's Avatar
Timmay Zoom Zoom
Thread Starter
Scooby Regular

Joined: Jun 2012
Posts: 120
Likes: 0
From: Hampshire
Default Intercooler pipe beading tool

Hi All,

Does anybody have an intercooler pipe beading tool that I could borrow? Ideally located close to basingstoke. Having a few issues where I cut the cooler hard pipes for a better fit and the couplers blows off, so wanting to put a bead on to help give the clamps a fighting chance at holding the couplers on.

Cheers
Reply
Old Mar 31, 2015 | 04:47 PM
  #2
JDM_Stig's Avatar
JDM_Stig
Scooby Regular
15 Year Member
Liked
Loved
iTrader: (3)

Joined: Feb 2009
Posts: 5,873
Likes: 44
From: Mount Weather
Default

Reply
Old Mar 31, 2015 | 04:54 PM
  #3
Timmay Zoom Zoom's Avatar
Timmay Zoom Zoom
Thread Starter
Scooby Regular

Joined: Jun 2012
Posts: 120
Likes: 0
From: Hampshire
Default

Cheers for that, I did watch that very same video before i posted. I couldn't find the tool in the video to use as a basis for mod, even after a number of web searches. Also if anybody had a proper tool that was not too far from me and would be willing to let me have a go, i reckon it would do a better job.
Reply
Old Mar 31, 2015 | 05:05 PM
  #4
kevo10's Avatar
kevo10
Scooby Regular

Joined: Oct 2010
Posts: 1,094
Likes: 0
From: Kings Norton, birmingham
Default

Try spraying the ends of the pipe and tubing with hairspray!!!! . Not tried myself .but apparently does work
Reply
Old Mar 31, 2015 | 08:25 PM
  #5
mickywrx's Avatar
mickywrx
Unmapped 12.4s @ 105
20 Year Member
iTrader: (29)

Joined: Apr 2005
Posts: 11,778
Likes: 4
From: Newcastle. 330bhp-289lb/ft @ 1bar boost - 12.4s @ 105mph
Post

Do you know anyone with a Tig welder? Could get a bead welded on both ends.

Or modify some mole grips, if you know someone with a normal welder.

From a thread I posted nearly 6 years ago on 22B.

Originally Posted by Playsatan
Have you access to a welder, a grider and a disposable pair of mole grops? If so try this.





Use the line to make sure you dont run off



Don't rush it. You might have to go round a few times to get it just right but you should end up with something like this.

Reply
Old Mar 31, 2015 | 08:49 PM
  #6
gazney101's Avatar
gazney101
Scooby Regular
iTrader: (5)

Joined: Sep 2012
Posts: 1,114
Likes: 8
From: co durham
Default

Originally Posted by mickywrx
Do you know anyone with a Tig welder? Could get a bead welded on both ends.

Or modify some mole grips, if you know someone with a normal welder.

From a thread I posted nearly 6 years ago on 22B.
I did a very similar thing with mine micky and very effective but i had cramp in my hand for 3 weeks after lol
